WB: GBF weighing system with increased accuracy, storage on USB stick

Weighing system for determining the amount of insulation material processed.
The creation of blow-in projects, e.g. individual elements or a logical group of elements and their activation is done directly at the weighing terminal.
Saving of individual weighing results to the USB stick placed in the terminal can be done externally via the digital inputs and outputs, by means of a remote button or appropriately programmed X-Floc (radio) remote control.
The weighing results are stored in tabular form in a CSV file, which can be evaluated with suitable software, e.g. spreadsheet.

---------------------------------------------------------------------------
Included in delivery:
4 pcs. Load cell up to 750.0kg (stainless steel) (item no. 10270)
4 pcs. Oscillating metal base / VA up to 2t (with height adjustment) (10622)
1 pc. Terminal box ZPK4 (item no. 4878) incl. 12 m shielded measuring cable
1 pc. Evaluation unit 83sigma (12-25V) (Art.-No. 11228)
1 pc. Evaluation unit 83sigma: Digital inputs/outputs (art.-no. 11235) incl. 4 m connection cable
1 pc. 83sigma evaluation unit: USB data logger IP65 (11237)
1 pc. Evaluation unit 83sigma: Programming of print image/weighing sequence/data record (art.-no. 11238)

---------------------------------------------------------------------------
Options:
