EM 500-400V-9,5kW High-powered insulation blowing machine View larger

EM 500-400V-9,5kW High-powered insulation blowing machine


New product

EM 500-400V-9,5kW High-powered insulation blowing machine


€ 0,00

Add to wishlist


Heavy duty insulation blowing machine for processing certified insulation materials, e.g. cellulose, wood fibre, rock wool and many more professionally. Due to its design, the machine is ideally suited for both stationary plant use and mobile use on-site.

Important features:
Different than conventional insulation blowing machines, the processing material will be fed into the machine at table height and transported with a conveyor belt to the conditioning unit. The 3-stage material conditioning unit, consisting of one shredder and two shredding shafts, can easily break up and finely shred highly compacted processing materials (max. 175kg/m³ packing density). The material flow volume can be set by the airlock feed gates position. A high-powered turbine generates the required air power effortlessly. All important machine settings can be set directly from the injection point by cable or radio remote control. The machine is equipped with one 400V/3x16A power connections. For more information, see product data sheet.

Technical details:
- Power/material throughput: up to 1800kg/h (based on cellulose), depending on application, material and delivery
- Hopper volume: 0,4 m³
- Dimensions: 1520 x 800 x 1300 (L x W x H)
- Empty weight: 390 kg
- Filling height: 860 mm
- Conditioning: 2x shredding shafts, 1x shredder
- Material setting: controllable via control by setting the electrical airlock feed gate or via the airlocks rotational speed (DS-option)
- Machine control: cable control KFB2000 (standard) or FFB2000/FFB2000-Pro (optional)
- Electrical connection: 1x 400V/50 Hz/3x16A/N/PE (+/- 5%) (electrical fuse Automat B or C or slow screw-in fuse)
- Inside the insulation blowing machine, frequency guided drives are installed. The electrical connection must be made according to the applicable national electrical regulations.
- Power rating: 9,5 kW
- Blower: high-powered turbine 7,5 kW
- Conveying pressure: max. 500 mbar
- Air flow (nominal/gauged): 490/450 m³/h
- Airlock volume: 36 L
- Outlet: NW75 (3'') (direct reduction to NW63 (2½'') or NW50 (2) possible)
- Airlock chamber ventilation for optimal processing throughputs
- Incoming air filter with quick fastener, NW90 intake air duct
(All values are approximate)

Scope of delivery:
- Fully functional insulation blowing machine, consisting of machine base, foldable machine top with dust curtain and dust-reducing connection, feed table
- Basic machine set, consisting of:
1x small-parts case with 1x cable remote control KFB2000 and carrying belt, 1x crank tool, 1x pressure gauge, 1x control cabinet key, 1x open-ended spanner NW13, 1x open-ended spanner NW24, 1x socket spanner NW13, 1x silicone spray, 1x hose clamp NW90, 1x quick-connect clamp NW75, 1x belt tension measuring device, 1× 400V/10m power cable (CEKON), 1x control cable on reel 50m, approx. 2m NW90 air suction hose, 1x reducer piece PE 90-76 with O-ring, machine folder incl. operating instructions, inspection records and EC declaration of conformity

Optional equipment:
- Radio remote control FFB2000 -Pro instead of cable remote control (prod. no. 5243 or 5154)
- Additional option AE - blow-off unit (prod. no. 4038)
- Additional option DS - adjustable airlock rotation speed (prod. no. 5060)
- Mounting foot (prod. no. 5301)
- Intake socket 90° NW90 (prod. no. 5613)
- Direct extension NW75-90 (3-3,5) (prod. no. 6746, conveyor line NW90 (3,5) necessary)
- Accessory set for loose insulation material NW75/63 (3/2,5) (nonabrasive, prod. no. 5246)
- Accessory set for loose insulation material NW75/63/50 (3/2,5/2) (nonabrasive, prod. no. 5737)
- 400V phase adaptor and neutral conductor monitor with cut-out protective system (prod. no. 4553)
- Insulation blowing tools (various prod. no.)
- For more accessories, see price list / available on request
