Power generator XM15kVA/12kW Diesel (Silent/IP23)

Power generator for operating an X-Floc insulation blow-in machine and suitable machines and consumers with high starting current. The housing is soundproofed, so this generator is very quiet in operation.

------------------------------------------------------------------------------
Features:
- Electric starter with ignition key
- Voltage control (electronic)
- Clear connection and control panel
- Multiple display/operation:
(Function) preheating
(Display) e.g. voltage, frequency, speed, hour counter etc.
(Alarm) signalling, e.g. oil pressure, temperature, voltage etc.
- Fuel level display
- Built-in horn
- Emergency stop switch
- Remote control connection
- Central (crane) lifting eye
- Preparation for automatic emergency power supply EAS
- Very easy to maintain, the housing can be opened completely
- Ground fault circuit interrupter
- Earth terminal
- Conforms to EU directives for noise and safety

---------------------------------------------------------------------
Technical data:
- Power 3-phase LTP: 15kVA (12kW), 400V, 21.6A
- Power 3-phase PRP: 14kVA (11.2kW), 400V, 20.2A
- Power 1-phase PRP: 6.5kVA , 230V, 28.3A
- Connections:
1x 400V/32A CEE
1x 400V/16A CEE
1x 230V/16A CEE
1x 230V/16A Schuko
- Motor speed: 1500 rpm
- Engine cooling: Water
- Fuel: Diesel
- Tank capacity: 60 l
- Running time at 75% PRP: approx. 23 h
- Sound level (guaranteed / measured): 92 db(A) / 91 db(A)
- Protection class: IP23
- Dimensions: 1,720 x 1000 x 1,127 mm (L x W x H)
- Empty weight: approx. 565 kg

---------------------------------------------------------------------
For example, suitable for the following machine types:
- EM100, EM100 + VS28, EM100 + VS33, EM100 + VS55M
- M99, M99 + VS28, M99 + VS33
- M99-DS, M99-DS +VS28, M99-DS +VS33
- M99-DS-Pro, M99-DS-Pro + VS28, M99-DS-Pro + VS33
- M95-230V, M95-230V + VS28, M95-230V + VS33
- M95-2x230V, M95-2x230V + VS28, M95-2x230V + VS33
- M95-400V, M95-400V + VS28
- M95-2x230V, M95-400V
- EM320, EM340, EM360
- EM400

---------------------------------------------------------------------
Optional accessories on request (selection):
- Remote control
- Lockable tank cap
- earthing kit
- site chassis
- road chassis
