Power generator XM20kVA/16kW Diesel (Silent/IP44/IsoG)

Power generator for operating an X-Floc insulation blowing machine and suitable machines and power consumers. The housing is soundproofed, making this power generator particularly quiet in operation.
Due to the integrated insulation monitoring, this power generator protects human and machine particularly well against entanglement and damage caused by possible isolation faults. The number of machines connected to the power generator and the cable lengths are no longer limited.

------------------------------------------------------------------------------
Features:
- Electric starter with ignition key
- Voltage regulation (electronic)
- Insulation monitoring (earth spike no longer required!)
- Version in accordance with DGUV variant B with all-current sensitive miniature circuit breakers
(B-Class) for the 2nd and each additional socket outlet.
- Clearly arranged connection and control panel, can be secured with a lock
- Particularly long runtime (29.5h at 75% of PRP)
- Multiple (alarm) signalling, e.g. oil pressure, temperature, voltage, etc.
- Central (crane) lifting eye
- Preparation for automatic emergency power supply EAS
- Housing shape and sealed base provide increased protection against water ingress and liquid run-off (better environmental protection) and a high protection class (IP44)
- Very easy to maintain, the housing can be generously opened
- Complies with EU directives for noise and safety

---------------------------------------------------------------------
Technical data
- Engine: Yanmar diesel Stage 5
- 3-phase LTP power: 20kVA (16kW), 400V, 28.9A
- 3-phase PRP power: 18kVA (14.4kW), 400V, 26A
- Power 1-phase PRP: 7kVA, 230V, 30.4A
- Connections:
1x 400V/32A CEE
1x 400V/16A CEE FI type B
2x 230V/16A Schuko FI- type B
- Motor speed: 1500 rpm
- Engine cooling: Water
- Fuel: Diesel
- Tank capacity: 100 litres
- Running time at 75% PRP: approx. 29.5h
- Sound level value (guaranteed / measured): 89 db(A) / 88 db(A)
- Protection class: IP44
- Dimensions: 1,835 x 900 x 1,264 mm (L x W x H)
- Unladen weight: approx. 750 kg

---------------------------------------------------------------------
Optional accessories on request (selection):
- Transport carriage
- Remote control
- Earthing kit
- Construction site chassis
- Road chassis
