EMX250 Special insulation blowing machine View larger

EMX250 Special insulation blowing machine


New product

EMX250 Special insulation blowing machine


€ 0,00

Add to wishlist


Compact insulation blowing machine for processing certified insulation materials, e.g. rock wool, mineral wool, glas wool, wood chips, hemp hurds, cellulose and others. Due to its design, the machine is ideally suited for mobile use on-site.

Important features:
The 2-stage material conditioning unit, consisting of one screw conveyor and one shredding shaft, can easily break up and finely shred compacted processing materials. Two high-powered radial fans generate the required air power effortlessly. All important machine settings can be set directly from the injection point by radio remote control. The machine is equipped with two 230V/10-16A power connections. For more information, see product data sheet.

Technical details:
- Power/material throughput: up to 500 kg/h (based on cellulose), depending on application, material and delivery
- Hopper volume: 0,26 m³ (with wooden top piece), 0,15 m³ (without wooden top piece)
- Dimensions: 1200 x 600 x 1750 (L x W x H)
- Empty weight: 240 kg
- Filling height: 1630 mm (with wooden top piece), 1370 mm (without wooden top piece)
- Conditioning: 1x screw conveyor, 1x shredding shaft
- Material volume: adjustable, speed regulator screw conveyor (electrical switchboard)
- Machine control: radio remote control FFB500, material ON, air ON, OFF, setting switching on/off-delay times, key lock, battery status display
- Electrical connection: 2x 230V/50 Hz/10-16A/PE (+/- 5%)
- Inside the insulation blowing machine, frequency guided drives are installed. The electrical connection must be made according to the applicable national electrical regulations.
- Power rating: 4,2 kW
- Blower: 2x high-powered radial fans 2x 1,45 kW
- Air volume: adjustable, blower regulator (electrical switchboard)
- Conveying pressure: max. 310 mbar
- Air flow (nominal/gauged): 440/370 m³/h
- Outlet: NW63 (2½'') (direct reduction to NW50 (2) possible)
- Airlock chamber ventilation for optimal processing throughputs
(All values are approximate)

Scope of delivery:
- Fully functional insulation blowing machine, consisting of machine base on wheels, machine top with hopper storage top piece and foldable sack support
- Basic machine set, consisting of:
1x small-parts case with 1x radio remote control FFB500, 1x control cabinet key, 1x socket spanner NW13, 1x silicone spray, 2x power adapter 230V 10m ring, approx. 2m NW75 air suction hose, 1x reducer tube 63-50, machine folder incl. operating instructions, inspection records and EC declaration of conformity

Optional equipment:
- Insulation blowing tools (various prod. no.)
- For accessories, see price list / available on request
