Injection nozzle NW50-29 AV-WE (with shut-off valve, interchangeable insert pipe NW29, straight outlet)

Rigid injection nozzle with shut-off valve for blowing in and post-compacting loose insulation materials.

------------------------------------------------------------------------------
Advantages:
- Shut-off valve for fast, efficient insulation material processing
- Exchangeable nozzle tube, secured by a wing screw
- For large insertion depths, the use of very long tubes is possible

------------------------------------------------------------------------------
Technical data:
- Outer diameter: 29.1 mm
- Insertion length: approx. 130 mm (standard)
+++ Other lengths available upon request, please specify when ordering +++
- Material: Steel
- Weight: approx. 0.81 kg
- Hose connection: NW50 (2'')
- Required drill hole: -29.1 mm
- Valve: Ball valve

------------------------------------------------------------------------------
Optional Accessories:
- DD: PE Spacer 29 (Item No. 2334)

++++++++++++++++++++++++++++++++++++++++++++++++++++

Working length (insertion length) deviating from standard (130mm): ___________ mm

++++++++++++++++++++++++++++++++++++++++++++++++++++
