Injection bezel foldable for panel thickness t 10..35mm

Handy tubing port for fastening in the drill hole with clamping mechanism and locking latch. Self-sealing against the structure element through breathable sealing sponges and dustproof rubber membrane.

Technical details/Features:
- Can be used with paneling depth s approx. 10 to 35mm
- Required drilling hole: D 106,5 to 120mm
- Rubber membrane to seal the injection bezel
- Default: Rubber membrane D 45 mm best suitable for hoses and injection needles NW50(2") to NW63(2½")
- Flexible sealing for avoiding dust emissions from the blowing port
- Ergonomic locking latch for easy opening and unlocking / useful for single handed operation
- Powder and electrogalvanized coating offer rust protection
- Including 1 x sealing sponge NW50/NW63, 250x250x20 (Art.No. 7160)
- Including 1 x sealing sponge NW50/NW63, 250x250x40 (Art.No. 7100)

Note / Option / Different versions possible (please specify when ordering)
-- Rubber membrane D 68 mm (Art.No. 9181) best suitable for hoses and injection needles NW63(2½") to NW75(3")
-- Rubber membrane D 30 mm (Art.No. 9180) best suitable for hoses and injection needles NW38(1½") to NW50(2")

Further Options:
- DDE: Hole saw with release system complete D 106,5mm (Art.No. 4966)
- DDE: Hole saw professional D 106,5mm (Art.No. 6182)
- DDE: Hole saw with release system complete D 120mm (Art.No. 5282)
- Sealing sponge with larger clearance hole (on request)
- Modifiable with "Fixierwinkel, L165, B60-20" (L-shaped hook, Art.No. 7005) to Injection bezel foldable for panel thickness T 3565mm (Art.No. 9183)
